CONTROLS AND ELEMENTS
Controls left cooking zone (2000 W max.)
Controls right cooking zone (1500 W max.)
1. Touch button on / off
2. Power LED indicator
Left cooking zone
3. Touch button function selector
4. LED screen
5. Touch up button
6. Touch down button
7. LED power mode selected
8. LED temperature indicator of the selected mode
9. LED indicator activated timer mode
10. Touch Jump button at maximum power or temperature
11. Touch Jump button at minimum power or temperature
10 11
7
8 9 23
5
4
6
1
19 20
16
17 18 12
14
13
15
