mxr FOD - Controls and Operation; External Controls

M251 | FOD
™
Drive 2
1 BLEND knob sets mix of High Gain and Crunch Gain circuits
2 OUTPUT knob sets overall volume
3 GAIN knob sets intensity of High Gain circuit’s overdrive
4 SCOOP switch selects flat, scooped, or boosted midrange frequencies
5 TONE knob controls overall EQ
6 FOOTSWITCH toggles effect on/bypass (clear blue LED indicates on)
1
2
5
3
4
6
External Controls
