M251 | FOD
™
Drive 5
Specifications
*A-weighted, Midrange control in up position, all other controls at mid position
Input Impedance
770 kΩ
Output Impedance
<900 Ω
Nominal Output Level*
-8 dBV
Noise Floor* -89 dBV
Tone Control ±5 dB, 10 kHz
Scoop Switch
Up Position Flat
Mid Position +5 dB, 600 Hz
Down Position -8 dB, 1 kHz
High Gain +9 dB to +70 dB, 1 kHz
Crunch Gain +2 dB to +45 dB, 1 kHz
Bypass True Hardwire
Current Draw 11 mA
Power Supply 9 volts DC
