MXR | Power 50 4
Specifications
Input Impedance
700 KΩ
Output Impedance 900 kΩ
Return Impedance 1 MΩ
Send Impedance 10 KΩ
Nominal Output Level* -12 dBV
Maximum Output Level 0 dBV
Nominal Send Level* -26 dBV
Controls
Bass +4 dB, -21 dB, 50 Hz
Mid ±7 dB, 500 Hz
Treble ±7 dB, 5 kHz
Treble*** +7 dB, -21 dB, 5 kHz
Presence +7 dB, 4 kHz
Bypass True Hardwire
Current Draw 12 mA
Power Supply DC 9 volts
* All controls at mid position
**A-weighted, all controls at mid position
***MID control at maximum counterclockwise position 0 dBV= 1 Vrms
