5-8
5.3.2 Replacement Parts
Prepare genuine replacement parts.
Table 5-7 and table 5-8 are lists of standard parts to be replaced when i-series compressor overhauled.
When purchasing any part, inform its (a) model, (b) serial number, (c) part name, (d) part code and
(e)
required number to our sales offices or service centers.
The serial number (b) is especially required among them. Unless serial number is informed, it is difficult
to identify design and production specification details that are needed to identify the part you want to
purchase.
Table 5-7 Replacement parts of i125*
P/N Part name Code No. Remarks Qty
6-1 Gasket, Suction Adapter CS00600-I125 i125 1
6-2 Gasket, Strainer Cover CS00900-I125 i125 1
7 O-ring see Note 1 PA12-140 JIS B 2401 G140 1
12 Gasket, Bearing Head CS01200-I125 i125 1
17 Gasket, Bearing Cover CS01700-I125 i125 1
23 Gasket, End Cover CS02300-I125 i125 t=1.0 1
27-1 Radial Bearing CS02800-FM125M NU2308ET7 2
27-2 Radial Bearing CS02800-FM125F NU2309ET7 2
30
Balance Piston see Note 2
CS03000-I125 i125 1
33 Sleeve, Balance Piston see Note 2
CS03300-I125 i125 1
35 O-ring see Note 1 PA11-016 JIS B 2401 P16 1
38-1 Thrust Bearing M CS03800-I125MP Shared with i125M,FM11S 1
38-2 Thrust Bearing F CS03800-125FP Shared with i125F,125 1
40-1 Lock Washer NG32-008 AW8 1
40-2 Lock Washer NG32-009 AW9 1
49 O-ring see Note 1 PA12-085 JIS B 2401 G85 1
50 Oil Seal see Note 2
CS05000-125D 125*** Rareflon 1
52 Gasket, Seal Cover CS05200-125N 125*** 1
100
Mechanical Seal Assembly see Note 3
CS10002-125EBS BBSE 125*** 1set
237-1 Torsional Slip Washer M CS23700-FM125M FM125 M 1
237-2 Torsional Slip Washer F CS23700-125 125L** 1
395 Gasket, Unloader Cover CS39500-I160 i160* 2
480 Strainer Element see Note 2
CS48000-I160 i160* 1
489 Valve Seat CS48900-I125 i125 1
491 Check Valve Shaft see Note 2
CS49100-I125 i125 1
495 O-ring see Note 1 PA11-007 JIS B 2401 P7 1
To Next Page
