myPhone D21 - Appearance of the Phone, Its Functions and Buttons; Technical Specifications

EN © 2020 mPTech. All Rights Reserved. D21
20
Technical Specifications
• Frequency ranges:
o GSM: 850 / 900 / 1800 / 1900 MHz
• Dual SIM; Loudspeaker mode
• Dimensions: 250 x 180 x 60mm
• Display: 2.4”
• Battery capacity: 800mAh
• Phone weight (with battery)561g
• Battery technical specification:
o Input: 100-240V~, 50/60Hz, 0,2A
o Output: 5V 0,5A
Appearance of the phone, its functions and buttons
1
Handset
Activates the call mode when the
user picks up the handset Stops the
call when the user hangs up.
2
Display
Monochrome screen.
3
Antenna
Improves GSM signal coverage.
4
Safety
measures
Removed and mounted on the
reverse side protects the handset
from falling when the phone is
mounted vertically.
5
External
speaker
Loudspeaker for system tones,
ringtones, music, and handsfree
operation
