Myzone Myzone2 - System Overview

01 Introduction
The MyZone 2 system had been developed to provide
individualised control over airow in each room.
Traditional zone selection systems provide two
position on or off control over airow often resulting
in over or under conditioning. The MyZone 2 system
allows the occupant of each room to adjust the
airow to precisely match their comfort target.
MyZone 2 comes standard with two touchpad ports.
MyZone 2 can operate with two types of
motorised dampers. The ZoneBoss Modulating
motor (default) or the Belimo LMU Series.
Damper selection is done through the Settings
menu. Other conguration features include
total zones present, favourites present, spill
display/hide, buzzer enable/disable.
MyZone 2 provides an unparalleled level of control
over the airow in every zone guaranteeing
that comfort expectations are met.
02 System Overview
MyZone 2 is ideally suited for any structure
with dynamic heat loads, especially residential
applications where individual requirement
differs for each room. The system is implemented
independently of the plant controller.
2.1 How it Works
Although the installation, commissioning
and operation of the system are simple the
actual control process is ingenious. The
operation can be separated into 3 areas:
 Individual Zone Airow Management
 Total Airow Management
 Safety Modes
2.1.1 Individual Zone Airow Management
One of the strengths of the MyZone 2 system is the
way it handles each zone as an independent entity.
The zone damper position can be adjusted for each
zone in ve percent increments providing precise
ow control in each room. A time proportional
damper positioning algorithm (TPDP) is used
to modulate and monitor damper position.
2.1.2 Total Airow Management
As damper positions change in individual zones
MyZone 2 recalculates the total airow requirement
and uses a spill function to maintain system
operating pressures within acceptable range.
2.2 System Components
The MyZone 2 system is tailored to suit each
application by incorporating the following
components into a standard ducted HVAC system.
 MZWFCBT8-V2 (Control Box & Transformer)
 MZWFTP8-V2 (MyZone 2 Touch Screen)
2.2.1 MZWFCB8-V2
The MyZone 2 Control Box includes eight damper
outputs, 2 touchpad ports and spill selection.
2.2.2 MZWFTP8-V2
The MyZone 2 Touch Screen provides an interface
for precise damper positioning and user control.
