N'Finity pro HDX - Built-In Installation Requirements

(b) Installation of Unit as a Built-In Cellar
The cutout dimensions illustrated below allows for door clearance and access to the pull-out shelves when
installed as a built-in appliance. Your wine cellar has been manufactured with a zero clearance door so no
extra space is required to account for the door swing when building into cabinetry.
34
1
4
"
5
1
4
"
23
3
4
"
23
"
34
3
4
"
25
"
24
3
4
"
These cut out dimensions show the minimum space required for your wine cellar to perform as designed.
Note:
If your cabinets are less than 34 ¾” in height, you can remove the leveling legs on the bottom of the wine cellar to
reduce it’s height by ½”. You must use shims to level the wine cellar if you remove the leveling legs.
