N4L IMP161 - Specification

IMPxxx Series User Guide
Connections for a single phase Impedance Network
The diagram on the following page illustrates the connections
required to connect the AC Source, IMP161 Impedance
Network, and PPA5511 Power Analyzer.
Make connections as shown:
AC Source – Impedance Network
L – L
N – N
GND - GND
Impedance Network – PPA5511 Power Analyzer
4mm Yellow Lead – A Hi – A Hi
4mm Black Lead – A Lo – A Lo
4mm Red Lead – V Hi – V Hi
4mm Black Lead – V Lo – V Lo
IMPxxx Series User Guide
Specification
Type
IMP161/3
IMP321/3
IMP753
Current Rating
16Arms
32Arms
75Arms
Impedances
Phase Conductors
(L1, L2, L3)
R:240mΩ
X: 150mΩ @50Hz X:180mΩ @ 60Hz
Neutral
Conductor
R:160mΩ
X: 100mΩ @50Hz X:120mΩ @ 60Hz
Phase to Neutral
Impedance
R:400mΩ
X: 250mΩ @50Hz X:300mΩ @ 60Hz
Cooling
Air Cooled
Dimensions
W450mm x D 500mm
Height
4u
6u
8u
