If any particle adheres to the mounting surface, appropriate installation accuracy cannot be obtained.
It could cause deterioration of performance, such as abnormal noise and vibration, and also lead to
damage of the motor.
* There are various ways to install the motor, depending on the shape of the reduction gear or
customer’s equipment. For the installation methods other than the above examples, check the
“External dimensions” drawings and specification sheet. If anything is unclear, contact our service
representative.
Fig. 5-38
Motor mounting flange
Motor
Motor
Input gear
