ENGLISH
8
GENERAL SPECIFICATIONS
TURNTABLE
Nominal speed 33/45 rpm, manual speed change (78 rpm possible with special pulley)
Speed variance 33rpm: < ± 0.50 %, 45rpm: < ± 0.45 %
Wow and utter 33rpm: < ± 0.15 %, 45rpm: < ± 0.15 %
Signal to noise -68 dB
Downforce range 0 - 30 mN
0 - 3.0 grams
Supplied counterweight system Counterweight for cartridges: 5 - 12 g
Voltage Universal switch mode power supply: 15 V DC/0.8 A, 100-240 V AC, 47 - 63Hz
Power consumption 5 W maximum
0.3W standby mode
TONEARM
Eective tonearm mass 9.5 g
Eective tonearm lenght 230 mm
Overhang 18 mm
ORTOFON OM 10 CARTRIDGE
Frequency range 20 Hz - 22 kHz
Channel separation 22dB/1kHz
Output voltage 4mV
Recommended load impedance 47k Ohms
Amplier connection MM-input
Compliance/stylus type 20µm/mN – elliptical
Recommended tracking force 15mN
Weight 5g
DIMENSION AND WEIGHT
Gross dimensions (W x H x D) 435 x 340 x 125mm
17 ⁄ x 13 ⁄ x 4 ⁄ inches
Shipping weight 8 kg (17.6 lbs)
Specifications are subject to change without notice. For updated documentation and features, please check out www.NADelectronics.com for the latest information about C 558.
SPECIFICATIONS
