NAD VISO TWO - Page 40

5-INPUT 3-OUTPUT VIDEO SWITCH
• mlh{|ylz
• 5-input 3-output
• Operating Voltage p4.0 to p6.5V
• Operating current p15mAtyp. at Vcc=p5V
• Crosstalk -65dBtyp.
• Internal 6dB Amplifier
• Internal 757 Driver
• Bipolar Technology
• Package Outline DIP16,DMP16
• GwpuGjvumpn|yh{pvuGGisvjrGkphnyht
13
9
7
5
3
20k
20k
20k
20k
16
10 14 2
1
15
11
81264
6dB
Amp
757
Driver
S3
S2
S4
S1
20k
20k
20k
S5
S6
S7
Vin1
Vin2
Vin3
Vin4
Vin5
SW3 SW4
SW5SW1SW2V
+
GND V
-
Vout3
Vout2
Vout1
6dB
Amp
6dB
Amp
75
7
Driver
75
7
Driver
2-29
VIDEO SW IC (NJM2595) : IC51, IC52, IC53
