NAD VISO TWO - Page 53

2-42
TO-92S
1. Emitter
2. Collector
3. Base
1. Emitter
2. Collector
3. Base
KRA102M
KSC2785Y
KSA1175Y
KTC3200GR
KTA1271Y
KTA1268GR
KSB811Y
KRC102M
KTC3114A
KTA1360Y
KTC3423Y
1. Emitter
2. Collector
3. Base
TO-126
TO-92
123
123
123
1. Base
2. Collector
3. Emitter
KTB1369Y
KTD2061Y
TO-220
1. Base
2. Emitter
3. Collecfor
12
3
KRA102S
KRC102S
KTD1304
SOT-23
1. INPUT
2. GND
3. OUTPUT
KIA7806
TO-220
123
123
1. INPUT
2. OUTPUT
3. GND
4. CONTROL
KIA78R05
KIA278R12
KIA278R05
KIA278R08
TO-220
1234
1. INPUT
2. OUTPUT
3. GND
TO-220
123
KSC2316Y
1. Emitter
2. Collector
3. Base
TO-92L
123
1. Base
2. Collector
3. Emitter
2SB1559
2SD2389
TO-3P
123
TRANSISTOR, REGULATOR IC BLOCK DIAGRAM
TOP VIEW
