Dynamic Enhancer Section (Operation)
Dynamic enhancement allows for selective replacement of high-end loss accrued through use of compression. As the signal level
rises towards the threshold point where compression will occur, high frequency enhancement is added at the same degree to
which the input signal is compressed. The Compressor/Limiter accurately tracks the amount of compression in order to compen-
sate with the same amount of dynamic enhancement, even if there are heavy signal variations. When there is no compression,
the signal is not enhanced. For more versatility, a PROCESS control allows you to control the available amount of dynamic
enhancement.
12. PROCESS CONTROL:
The PROCESS control sets the available amount of enhancement on a relative scale between Off and 6. Dynamic enhancement
allows you to replenish any high frequencies lost through the compression process for absolutely natural sounding dynamics
control. Enhancement is only added when compression is taking place.
13. MODE (STEREO/MONO) Switch:
The MODE switch can be used to select either Stereo or Mono operation as marked. In stereo mode, both channels operate
independently and all the separate channel controls are functional for both channels. In the MONO (depressed button) mode,
the controls of Channel 1 take over all the functions of Channel 2 with the exception of the IN/OUT and the PROCESS control of
the Dynamic Compressor Limiter.
9
