Nagman MTC Series User Manual

NAG/IM/MTC1200/01/22 27
 The display will show the transmitter’s output signal in
mA.
 Comparing the SET temperature and the output signal of
the transmitter.
Connection of Thermostat Switch :
 Connect the terminals placed on the front panel of the
calibrator to the thermostat switch to be powered and
calibrated.
 Place the thermostat switch into a correct sized insert in
the heating thermo well and set the desired calibration
temperature.
 Press select key then up arrow. Enter numeric key 1.
Test of thermostat switch point :
 Switch calibrator ON.
 Place the thermostat into a correct sized insert in the
heating thermo well.
 Ensure that thermostat is not connected to any other
voltage supply.
 Connect terminals of thermostat correctly to calibrator
switch test points and display will show either closed or
open condition.
 Select required temperature.
 When SET point of the thermostat is obtained, the
display will “freeze”

Nagman MTC Series Specifications

General

Brand	Nagman
Model	MTC Series
Category	Measuring Instruments
Language	English
