NAG/IM/MTC1200/01/22 6
2. SPECIFICATION
Range 300°C to 1200°C
Resolution 1°C
Accuracy ±2°C
Stability ±0.5°C
Stabilisation Time 15 Minutes
Temperature Readout °C / °F Selectable
Well Diameter 26 mm
Immersion Depth 105 mm
Dry Block Material Inconel
Heating Time
(Ambient to max.)
60 Minutes approx.
Cooling Time (to min.) 45 Minutes approx. (with Forced Air Cooling)
Switch Test facility Provided
Thermowell Dia 8 mm
Housing / Mounting Bench-top
Power Supply 230V AC, 50 Hz
Instrument
Dimensions
(L x D x H)
160 x 365 x 450 mm
Instrument Weight
(approx.)
15 Kg.
Measurement
Capability
Thermocouples ISA Types J, K, R, S, N, B, T
RTD Pt100 IEC Std.
mA 0 to 25 mA
mV 0 to 100 / 1000 mV
Volt 0 to 10 V
Resistance 0 to 500Ω / 3.5 KΩ
