21
Specifications
8 NDS Specifications
Audio Inputs
Sample rates supported: S/PDIF up to 24 bit 192kHz
USB: Front panel socket
UPnP™: Hi-Res UPnP playback up to 24bit/192kHz (WAV and FLAC)
Other inputs: Ethernet
Audio Outputs
Analogue outputs: DIN and RCA
Line outputs fixed (level): 2.2V rms at 1kHz
Output impedance: 30Ω maximum
Minimum load impedance: 10kΩ
Frequency response: 10Hz – 20kHz, +0.1/-0.5dB
THD+N: <0.1%, 10Hz –18kHz at full level
Phase response: Linear phase, absolute phase correct
Digital outputs (type): S/PDIF, 75Ω BNC
Upgrades DAC, Hi-Line
Connectivity
Digital inputs: BNC, Coaxial RCA and TosLink
Infra red: RC5
Remote input: 3.5mm jack on rear (RC5)
Remote output: 3.5mm jack on rear (RC5) x2
Ethernet: RJ-45, Cat5E, WiFi
USB: Front panel socket (Max rating: 5V at 1000mA)
USB: Rear panel mini-B socket (for software upgrade/diagnostics
only)
Formats
Audio formats supported: Internet radio (Windows Media-formatted content, MP3
streams, MMS)
Playlists (M3U, PLS)
MP3, AAC (up to 320kbit/s, CBR/VBR), M4A, ALAC
Windows Media-formatted content-9 (up to 320kbit/s)
WAV and FLAC (up to 24bit/192kHz via UPnP™ or USB only)
AIFF, LPCM 16/24, Ogg Vorbis
iRadio service provider: vTuner 5* full service
User Control Interfaces
Front panel: Nine button matrix.
Handheld: Remote handset and optional n-Stream App interface for
iPhone, iPod touch and iPad models. App downloadable
from the iTunes App store.
Power
Power supply options: XP5 XS, XPS or 555PS
Certifications and Licenses
Certifications: vTuner Premium
Licenses: MP3, AAC,
Physical
Dimensions: 87 x 432 x 314mm (H x W x D)
Weight : 13.5Kg
Note: Specifications may be subject to revision.
Naim Audio Limited
Southampton Road,
Salisbury,
England SP1 2LN
Tel: +44 (0)1722 426600
Fax: +44 (0)871 230 1012
W: www.naimaudio.com
Part No. 12-001-0167 Iss. 1L
