NDX Specifications
8 NDX Specifications
Audio Inputs
Sample rates supported: S/PDIF up to 24 bit 192kHz
USB: Front panel socket
UPnP: Hi-Res UPnP playback up to 24bit/96kHz (WAV and FLAC)
Antenna inputs: DAB/FM, WiFi
Tuning range: DAB (Band lll and L Band), FM 87.5-108MHz
Other inputs: Ethernet
Audio Outputs
Analogue outputs: DIN and RCA
Line outputs fixed (level): 2.1V rms at 1kHz
Output impedance: 10Ω maximum
Minimum load impedance: 10kΩ
Frequency response: 10Hz – 20kHz, +0.1/-0.5dB
THD+N: <0.1%, 10Hz –18kHz at full level
Phase response: Linear phase, absolute phase correct
Digital outputs (type): S/PDIF, 75Ω BNC
Upgrades
Power supply: XPS, 555 PS
Other: DAC, Hi-Line, Power-Line
Connectivity
Digital inputs: BNC, Coaxial RCA and TOSLINK
Infra red: RC5
Remote input: 3.5mm jack on rear (RC5)
Remote output: 3.5mm jack on rear (RC5) x2
RS232: DE9 female (For software upgrade only)
Ethernet: RJ-45, Cat5E, WiFi
USB: Front panel socket (Max rating: 5V at 500mA)
Formats
Audio formats supported: Internet radio (Windows Media-formatted content, MP3
streams, MMS)
Playlists (M3U, PLS)
MP3, AAC (up to 320kbit/s, CBR/VBR)
Apple Lossless (from iPod)
Windows Media-formatted content-9 (up to 320kbit/s)
WAV and FLAC (up to 24bit/96kHz via UPnP or USB only)
AIFF, Ogg Vorbis
iRadio service provider: vTuner 5* full service
User Control Interfaces
Front panel: Nine button matrix.
Handheld: Remote handset and optional n-Stream App interface for
iPhone, iPod touch and iPad models. App downloadable
from the iTunes App store.
Power
Supply voltage: 100V, 115V, 230V; 50 or 60Hz
Power supply options: Internal integrated or External
Power consumption 60VA (maximum):
Certifications and Licenses
Certifications: Apple (made for iPod, iPhone), vTuner Premium
Licenses: MP3, AAC, DAB
Physical
Dimensions: 87 x 432 x 314mm (H x W x D)
Weight: 10Kg
Note: Specifications may be subject to revision.
