NAiS FP0-C10RS - User Manual

Questions and Answers

M
Michael ThompsonAug 9, 2025
Why is the ERROR/ALARM LED on my NAiS Controller ON?
- B
  Brenda LongAug 9, 2025
  The ERROR/ALARM LED might be on for several reasons: * The system watchdog timer may have been activated, stopping FP0 operation. To resolve this, set the mode switch from RUN to PROG. and cycle the power OFF and then ON. * The program execution time might be too long. Review your program for instructions like JP or LOOP that could prevent a scan from finishing. * Interrupt instructions might be executed in succession. * You can also try setting the mode switch from PROG. to RUN.
J
James BruceAug 19, 2025
What to do if the ERROR/ALARM LED is blinking on my NAiS FP0-C10RS Controller?
- T
  Teresa FlowersAug 19, 2025
  If the ERROR/ALARM LED is blinking, it indicates a self-diagnostic error or a syntax error in the program. Here's what you can do: * Check the error code using the programming tool. * If there's a syntax error, switch to PROG. mode and clear the error. You can also execute a total-check function to pinpoint the syntax error's location. * For self-diagnostic errors other than syntax errors, use the programming tool in PROG. mode to clear the error. * In PROG. mode, turning the power OFF and then ON again can clear the error, but note that this will erase the operation memory (except hold type data). * Alternatively, you can clear the error by executing a self-diagnostic error set instruction F148 (ERR).
S
Steven HutchinsonAug 29, 2025
How to troubleshoot if all LEDs are OFF on NAiS Controller?
- R
  Rebecca Floyd DDSAug 29, 2025
  If all LEDs are OFF on your NAiS Controller, try the following: * Check the power supply wiring. * Ensure the power supplied to the FP0 control unit is within the rated range. * If the FP0 control unit shares its power supply with other devices, disconnect their power supply wiring. * Consider using a separate power supply for other devices or increasing the capacity of the current power supply.

Summary

Before You Start: Installation and Setup

Chapter 1: FP0 Overview

FP0 Components

Details the different types of FP0 control units and expansion units available.

FP0 Programming Tools

Lists and describes software and hardware for programming the FP0 controller.

Chapter 2: FP0 Control Units

FP0 Control Unit Parts and Terminology

Identifies and defines the key parts and terminology of FP0 control units.

FP0 Control Unit Specifications

FP0 Control Unit Pin Layouts

Chapter 4: FP0 Analog I;O Unit

FP0 Analog I;O Unit Parts and Terminology

FP0 Analog I;O Unit Specifications

FP0 Analog I;O Unit Wiring

Provides instructions for connecting analog input and output signals.

Chapter 6: FP0 Installation

Adding FP0 Expansion Units

Step-by-step guide on how to connect expansion units to the FP0.

FP0 Attachment to DIN Rails

FP0 Installation with Slim Type Mounting Plate

FP0 Installation with Flat Type Mounting Plate

Chapter 7: FP0 Wiring

FP0 Wiring Safety Instructions

Critical safety guidelines for wiring FP0 control units and devices.

Wiring the FP0 Power Supply

Detailed instructions for connecting the power supply to the FP0 control unit.

FP0 Grounding Procedures

Guidelines for proper grounding to ensure noise suppression and safety.

FP0 Input Wiring Guide

Instructions and examples for wiring various types of input sensors.

FP0 Output Wiring Guide

Instructions for output wiring, including protective circuits for loads.

FP0 Terminal Type Wiring

FP0 MOLEX Connector Wiring

FP0 MIL Connector Wiring

FP0 RS232 C Port Wiring

Chapter 9: FP0 Trial Operation

Pre-Operation Checks for FP0

Checks to perform before turning on the power to the FP0 controller.

FP0 Power On Procedure

Steps for turning on the FP0 controller and performing initial checks.

Chapter 10: FP0 Self-Diagnostic and Troubleshooting

FP0 Self-Diagnostic Function

Explains the self-diagnostic function and LED status indicators.

FP0 Troubleshooting Guide

Provides solutions for common errors and operational issues.

FP0 Error Codes Reference

Lists and explains error codes for syntax and self-diagnostic errors.

NAiS FP0-C10RS Specifications

General

Model	FP0-C10RS
Category	Controller
Manufacturer	NAiS (Panasonic)
Input Voltage	24 VDC
Number of Inputs	6
Number of Outputs	4
Output Type	Relay
Programming Language	Ladder Logic
Type	PLC
Communication Ports	RS-232
Program Memory	2K steps
Operating Temperature	0 to 55 °C
Storage Temperature	-20 to 70 °C
Humidity	35 to 85% RH (no condensation)
Dimensions	90 x 75 x 60 mm
Weight	300 g
