TRIPLE TURN Manual
．4．
4. Installation of LCD Box Unit
Top Tray L 1pcs
Screw M5X20 10pcs
Please open the inner cover of the machine cabinet and link the
connector of the top roof to LCD Box Unit;
Take off the inner cover of LCD Box Unit and connect black cable to the
displayer;
