NANO FONT - Module Layout and Controls; Frequency and Resonance Controls; CV Inputs and Attenuverters; Audio and Filter Outputs

CVF CVR
FREQ
RES
+-
+-
CVF
LP2 BP2
CVROCT
IN
FONT
Frequency
Cutoff Control
Resonance
Q Control
CV Frequency
Attenuverter
CVF Input Control
CV Frequency
Input
1V/Octave Input
Un-attenuated Frequency CV,
calibrated for 1V/Oct
Audio
Input
CV Resonance
Attenuverter
CVR Input Control
CV Resonance
Input
2-Pole Band Pass
Output
2-Pole Low Pass
Output
NANO Modules - València 2019 ©
Layout
This image will clarify the function of each of the elements of the module.
FONT
