COMPONENT PARTS
Please check that you have all the parts listed below
Medium Long Bolt
M6x50mm x 4
ASSEMBLY HARDWARE
FE G
H
1.Table top ×1
2.Tablecase left ×1
3.Tablecase right ×1
4.Table shelf support ×1
5.Table shelf support ×1
6.Bottom shelf ×1
7.Middle shelf ×1
Wood Dowel Pin
8 x 30
B
A
C
D
x 1
x 4
Allen Wrench
Page 4 of 8
15×11mm ×3
4×35mm ×4
6×40mm ×3
10×10mm
Allen Wrench
(included)
Tools Required
Phillips Screwdriver
(Medium) (not included)
*Do Not Use Power
Screwdriver or Drill.
Cam Lock Cam Bolt
Screw
Barrel Nut
Plug
