Napoleon EF36H - Page 7

7
W415-0544 / 10.31.05
Corner Installation
Front View
EF36
Note: In order to avoid the possibility of exposed insulation or vapour barrier coming in contact with the fi replace body, it is
recommended that the walls of the fi replace enclosure be “fi nished” (ie: drywall/sheetrock), as you would fi nish any other
outside wall of a home. This will ensure that clearance to combustibles is maintained within the cavity.
Top View
