D25PL-IKC
Quantity Description NAT Part #
1 D-min 25 Pin Housing 20-11-025
25 MS Crimp Pin 20-26-891
1* Jack Screw Set 20-27-002
1* Lock Clip Set 20-27-004
1 25 Pin Connector Hood 20-29-026
* Use as required.
2.6 Installation Drawings
DRAWING REV. DESCRIPTION TYPE
AA12-001
AA12\001\403-0 1.10 Compact Audio Controller Interconnect
AA12\001\405-0 1.12 Compact Audio Controller Connector Map
AA12\001\905-0 1.12 Compact Audio Controller Faceplate
AA12\001\922-0 1.10 Compact Audio Controller Mechanical Installation
AA12-002
AA12\002\403-0 1.00 Compact Audio Controller Interconnect
AA12\002\403-1 1.00 Compact Audio Controller Interconnect
AA12\002\405-0 1.00 Compact Audio Controller Connector Map
AA12\002\905-0 1.01 Compact Audio Controller Faceplate
AA12\002\922-0 1.00 Compact Audio Controller Mechanical Installation
AA12T-002
Use AA12\002\403-0 1.00 Compact Audio Controller Interconnect
Use AA12\002\405-0 1.00 Compact Audio Controller Connector Map
Use AA12\002\905-0 1.01 Compact Audio Controller Faceplate
Use AA12\001\922-0 1.10 Compact Audio Controller Mechanical Installation
AA12T\IKC\922-0 1.00 AA12T Tray Assembly Mechanical Installation
Section 2 ends after these Drawings
