2.5 Accessories Required But Not Supplied
Installation kit p/n PTA12-IKC (crimp) is required to complete the installation. The kit
consists of the following:
NAT Part No. D25SV-IKC, 25-pin D-min Female Crimp Kit
Quantity Description NAT Part #
1 D-min 25 Socket housing 20-21-025
25 MS Crimp Socket 20-26-901
1 25 Pin JVL Hood/Locklever 20-29-250
2.6 Installation Drawings
DRAWING REV. DESCRIPTION TYPE
PTA12\100\403-0 1.11 POTS Telephone Adapter with Display Interconnect
PTA12\100\403-1 1.11 POTS Telephone Adapter with Display Interconnect
PTA12\100\403-2 1.11 POTS Telephone Adapter with Display
STX100 Option
Interconnect
PTA12\100\403-3 1.11 POTS Telephone Adapter with Display
Remote Hook Control Option
Interconnect
PTA12\100\403-4 1.11 POTS Telephone Adapter with Display
STX100/LMC01 Option
Interconnect
STX100\000\403-6 1.00 STX100 GLOBALSTAR
TM
Satphone Receiver System Interconnect
STX100\000\403-7 1.00 STX100 GLOBALSTAR
TM
Satphone Receiver System Interconnect
PTA12\100\405-0 1.01 POTS Telephone Adapter with Display Connector Map
PTA12\100\905-0 1.00 POTS Telephone Adapter with Display Faceplate
PTA12\100\922-0 1.01 POTS Telephone Adapter with Display Mech. Installation
Section 2 ends after these Drawings
