NI 446X Calibration Procedure 14 ni.com
7. Acquire data using the following function.
8. Stop the task using the following function.
9. Clear the task using the following function.
NI-DAQmx Function Call LabVIEW Block Diagram
Call DAQmxReadAnalogF64 with the
following parameters:
taskHandle:
myTaskHandle
numSampsPerChan: -1
timeout: 10.0
fillMode :
DAQmx_Val_GroupByChannel
arraySizeInSamps: 102400
reserved: NULL
readArray:
float64ArrayReturnValue
sampsPerChanRead:
int32PointerReturnValue
NI-DAQmx Function Call LabVIEW Block Diagram
Call DAQmxStopTask with the following
parameters:
taskHandle:
myTaskHandle
NI-DAQmx Function Call LabVIEW Block Diagram
Call DAQmxClearTask with the following
parameters:
taskHandle:
myTaskHandle
