Use the following label in Figure 8 if you are connecting the SCB-68A to the MIO connector on
NI 783xR/784x/784xR/785x/785xR models.
Figure 8. MIO Connector for NI 783xR/784x/784xR/785x/785xR
Note To connect to the MIO connector on NI 7830R models, instead use the label
in Figure 7.
+5V
+5V
D GND
DIO 0
D GND
DIO 1
D GND
DIO 2
D GND
DIO 3
D GND
DIO 4
D GND
DIO 5
D GND
DIO 6
D GND
DIO 7
1
35
2
36
3
37
4
38
5
39
6
40
7
41
8
42
9
43
MIO
AO 4
AO GND 4
AO 5
AO GND 5
AO 6
AO GND 6
AO 7
AO GND 7
DIO 15
DIO 14
DIO 13
DIO 12
DIO 11
DIO 10
DIO 9
DIO 8
51
17
50
16
49
15
48
14
47
13
46
12
45
11
44
10
MIO
AI 6+
AI 6-
AI GND 6
AI GND 7
AI 7+
AI 7-
AI SENSE
NC*
AO 0
AO GND 0
AO 1
AO GND 1
AO 2
AO GND 2
AO 3
AO GND 3
59
25
58
24
57
23
56
22
55
21
54
20
53
19
52
18
MIO
AI 0+
AI 0-
AI GND 0
AI GND 1
AI 1+
AI 1-
AI 2+
AI 2-
AI GND 2
AI GND 3
AI 3+
AI 3-
AI 4+
AI 4-
AI GND 4
AI GND 5
AI 5+
AI 5-
68
34
67
33
66
32
65
31
64
30
63
29
62
28
61
27
60
26
MIO
SCB-68A Quick Reference Label
R Series Devices - MIO Connector
NI 783xR/784x/784xR/785x/785xR
Direct Feedthrough
1 2 3
1
2
S1
S2
*NC: No Connect
