Chapter 3 VXI-MXI-2 Configuration and Installation
PCI-MXI-2 for Linux 3-16 ni.com
Onboard DRAM
The VXI-MXI-2 can accommodate up to two 1.35 in. DRAM SIMMs.
Table 3-1 lists the SIMMs you can use.
Table 3-1. VXI-MXI-2 DRAM Configurations
Bank 0 Bank 1 Total DRAM
National
Instruments
Option
Switch Setting
of S6
— — 0 — —
256 K × 32 or
256 K × 36
— 1 MB — ON
256 K × 32 or
256 K × 36
256 K × 32 or
256 K × 36
2 MB — ON
512 K × 32 or
512 K × 36
— 2 MB — ON
512 K × 32 or
512 K × 36
512 K × 32 or
512 K × 36
4 MB — ON
1 M × 32 or
1 M × 36
— 4 MB YES ON
1 M × 32 or
1 M × 36
1 M × 32 or
1 M × 36
8 MB — ON
2 M × 32 or
2 M × 36
— 8 MB YES ON
2 M × 32 or
2 M × 36
2 M × 32 or
2 M × 36
16 MB — ON
4 M × 32 or
4 M × 36
— 16 MB YES OFF
4 M × 32 or
4 M × 36
4 M × 32 or
4 M × 36
32 MB — OFF
8 M × 32 or
8 M × 36
— 32 MB YES OFF
8 M × 32 or
8 M × 36
8 M × 32 or
8 M × 36
64 MB YES OFF
