Chapter 4 VME-MXI-2 Configuration and Installation
PCI-MXI-2 for Linux 4-2 ni.com
Figure 4-1. VME-MXI-2 Parts Locator Diagram
1S2
2U21
3W2
4U20
5 DRAM Bank 1
6 DRAM Bank 0
456
1
2
3
