Chapter 3 Signal Connections
© National Instruments Corporation 3-9 NI 660x User Manual
PFI 15 P0.15 or CTR 6 SOURCE
1
PFI 16 P0.16 or CTR 5 OUT
PFI 17 P0.17
PFI 18 P0.18 or CTR 5 GATE
1
PFI 19 P0.19 or CTR 5 SOURCE
1
PFI 20 P0.20 or CTR 4 OUT
1
PFI 21 P0.21
PFI 22 P0.22 or CTR 4 GATE
1
PFI 23 P0.23 or CTR 4 SOURCE
1
PFI 24 P0.24 or CTR 3 OUT
PFI 25 P0.25
PFI 26 P0.26 or CTR 3 GATE
PFI 27 P0.27 or CTR 3 SOURCE
PFI 28 P0.28 or CTR 2 OUT
PFI 29 P0.29
PFI 30 P0.30 or CTR 2 GATE
PFI 31 P0.31 or CTR 2 SOURCE
PFI 32 CTR 1 OUT
PFI 33 Input only
PFI 34 CTR 1 GATE
PFI 35 CTR 1 SOURCE
PFI 36 CTR 0 OUT
PFI 37 Input only
PFI 38 CTR 0 GATE
PFI 39 CTR 0 SOURCE
1
Counters 4 through 7 are not available in NI 6601 devices.
Table 3-3. PFI Lines Used as Outputs (Continued)
PFI Line Possible Signals
