© National Instruments Corp. 19 NI 9421/9423
that provided by a standard wall outlet, for example, 115 V for U.S.
or 230 V for Europe.
Caution Do not connect the NI 9421/9423 with screw
terminal to signals or use for measurements within
Measurement Categories III or IV.
NI 9421 with DSUB Safety Voltages
Connect only voltages that are within the following limits.
Channel-to-COM .............................. 30 V max
Isolation
Channel-to-channel .................... None
Channel-to-earth ground
Continuous ........................... 60 VDC,
Measurement Category I
Withstand ............................. 1,000 V
rms
, verified by a 5 s
dielectric withstand test
Measurement Category I is for measurements performed on
circuits not directly connected to the electrical distribution system
referred to as MAINS voltage. MAINS is a hazardous live electrical
supply system that powers equipment. This category is for
