16. Call niFgen ni5433 Flatness Cal Adjust with the following settings:
• Measured Power (dBm): Power of the waveform present on CH 1 of the
PXIe-5413 and measured by the power sensor in the previous step in dBm
17. If the Flatness Cal Complete output of niFgen ni5433 Timebase Cal Adjust returns
FALSE, repeat steps 12 through 16 until Flatness Cal Complete returns TRUE.
Reverification
Repeat the Verification section to determine the as-left status of the PXIe-5413.
Note If any test fails reverification after performing an adjustment, verify that you
have met the test conditions before returning your PXIe-5413 to NI. Refer to the
Worldwide Support and Services section for information about support resources or
service requests.
Setting the Calibration Date and Due Date
After completing all verifications or reverifications, set the calibration date and a calibration
due date for the PXIe-5413 using either Measurement Automation Explorer (MAX) or the
LabVIEW NI System Configuration API.
NI recommends a calibration due date of the date of external calibration plus the external
calibration interval for the PXIe-5413.
• MAX—Navigate to the External Calibration section of the Settings tab and update the
Calibration Date and Calibration Due Date entries. Click Save.
• LabVIEW NI System Configuration API—Use the Update Calibration VI to set the
calibration date and calibration due date.
The calibration due date can be either a specific date or an interval in months.
Related Information
Password on page 5
Worldwide Support and Services
The NI website is your complete resource for technical support. At ni.com/support, you have
access to everything from troubleshooting and application development self-help resources to
email and phone assistance from NI Application Engineers.
Visit ni.com/services for NI Factory Installation Services, repairs, extended warranty, and
other services.
Visit ni.com/register to register your NI product. Product registration facilitates technical
support and ensures that you receive important information updates from NI.
18 | ni.com | PXIe-5413 Calibration Procedure
