National Instruments PXIe-5413 User Manual

Table 1. PXIe-5413 Test Equipment (Continued)
Equipment Recommended
Model
Where Used Minimum Requirements
Precision
frequency
reference
PXIe-6674T or
Rubidium
reference
Verifications:
• Timebase
accuracy
Adjustments:
• Timebase
Frequency accuracy:
100 ppb
The ability to PLL lock to
the oscilloscope.
DMM PXI-4071 Verifications:
• DC voltage
accuracy
• AC amplitude
accuracy
Adjustments:
• DC voltage
DC voltage range: ±5 V
DC voltage accuracy:
<40 ppm
AC voltage accuracy:
±0.1% of reading at 50 kHz
AC Input Range: 0.05 V
RMS
to 5 V
RMS
AC Input Impedance:
≥10 MΩ
Bandwidth: ≥100 kHz
Double banana
plug-to-BNC (f)
Pasternak PE9008 Verifications:
• DC voltage
accuracy
• AC amplitude
accuracy
Adjustments:
• DC voltage
Impedance: 50 Ω
SMA (m)-to-
BNC (m) cable
— Verifications:
• DC voltage
accuracy
• AC amplitude
accuracy
Adjustments:
• DC voltage
Frequency range: DC to
1 MHz
Impedance: 50 Ω
Length: <1 m
PXIe-5413 Calibration Procedure | © National Instruments | 3
