LED Indications
device setup registers to control the device,
reading from the device to monitor the device
status, or transferring data to or from the
device.
• Green—The module is controllable through
the soware.
ACTIVE
• O󽗿—The module is idle or locked to the
requested reference.
• Solid red—The PLL is unlocked or the
module temperature is out of the specified
operating range.
