Verifying Hardware Installation for Remote
Targets
You can verify that the system recognizes the NI PXIe-7820R by using Measurement &
Automation Explorer (MAX).
1. Launch MAX on the host computer.
2. Expand Remote Targets in the configuration tree and locate your system.
3. Install LabVIEW Real-Time Module 2014 SP1 and NI RIO Device Drivers February
2015 or later on your Remote Target.
a) Refer to the Installing Software on the Host Computer section for information about
installing software on the host.
b) Refer to the PXI Express Controllers User Manual at ni.com/manuals for
information on installing software on the target.
4. Under Remote Targets, find and expand Devices and Interfaces.
If the device does not appear, press <F5> to refresh the view in MAX. If the device does
not appear after refreshing the view, visit ni.com/support for troubleshooting
information.
Connecting the NI PXIe-7820R
NI recommends using the following cables and accessories with the NI PXIe-7820R:
• EMI suppression ferrites (777297-01)
• Shielded 68-Pin Connector Block for R Series DIO & HSDIO Products (782914-01)
• Shielded R Series High Speed Digital Cable, 1m (156166-01)
• Shielded R Series High Speed Digital Cable, 2m (156166-02)
Note NI is not liable for connections that exceed any of the maximum ratings of
input or output signals on the NI PXIe-7820R and on the computer chassis. Refer to
the NI PXIe-7820R Specifications, available at ni.com/manuals for the maximum
input and output ratings for each signal.
6 | ni.com | NI PXIe-7820R Getting Started Guide
