Naturela NPBC-V3C-1 User Manual

Electronic pellet burner controller – NPBC-V3C-1/ NPBC-V4C-1
NPBC-V3C - 1/ NPBC-V4C - 1 INPUTS AND OUTPUTS DESCRIPTION
Outputs Inputs
FM
Main fan
RT
Room thermostat. To this input could be
connected a normally opened or
normally closed contact, with no
additional voltage.
FSG
Fan for the flue gases
PS
Photo sensor
SF
Screw for fuel
RB
Reverse burning sensor
SB
Internal screw
B
Boiler temperature sensor
PH
Heating installation pump
WH
Water heater temperature sensor
PWH
Hot water heater pump
PT
pt100 high temperature sensor
IGN
Ignition heater
OD
Opened door switch (Optional)
FC
Fan for cleaning
LED
ACF
Analog controlled fan (Optional)
User Manual / ver 3.8 http://www.naturela-bg.com/en/ page 5 of 36

Naturela NPBC-V3C-1 Specifications

General

Brand	Naturela
Model	NPBC-V3C-1
Category	Controller
Language	English
