Nautilus NS200X
CABLES
Cable #1 - Low Row (136.5”)................
Cable #2 - Pulldown (216.25”) .............
Cable #3 - Leg Extension (164.25”) .....
HARDWARE
Flat Head Screw - M8 ............................
Flat Head Screw - M4 ............................
Hex Bolt 1/2” x 4 1/2”L ..........................
Hex Bolt 3/8” x 4 1/4”L ..........................
Hex Bolt 3/8” x 4”L ................................
Hex Bolt 3/8” x 3 1/4”L ..........................
Hex Bolt 3/8” x 3”L ................................
Hex Bolt 3/8” x 2 3/4”L ..........................
Hex Bolt 3/8” x 2 1/2”L ..........................
Hex Bolt 3/8” x 2 1/4”L ..........................
Hex Bolt 3/8” x 2”L ................................
Hex Bolt 3/8” x 1 3/4”L ..........................
Cap Head Allen Screw 1”L ....................
Button Head Allen Screw 3/4”L ...........
1/2” Flat Washer ....................................
3/8” Flat Washer ....................................
1/2” Lock Nut..........................................
3/8” Lock Nut..........................................
Pulley Spacer .........................................
Step Spacer - 5/8”H ...............................
Step Spacer - 7/8”H ...............................
Set Screw 5/16” x 1/4”L ........................
Cap Head Allen Screw 3”L ....................
3/8” Curved Washer ..............................
ACCESSORIES and TOOLS
Lat Bar.....................................................
Rower Bar ...............................................
AB Strap .................................................
Felt Back Ankle Strap.............................
Dual Ring Handle ...................................
Chain .......................................................
Cable Clip ...............................................
Weight Selector Pin ...............................
Workout Chart ........................................
M4 Allen Wrench ...................................
M5 Allen Wrench ...................................
M6 Allen Wrench ...................................
M8 Allen Wrench ...................................
PARTS LIST / BOX CONTENTS
# DESCRIPTION QTY # DESCRIPTION QTY
Main Base Frame ....................................
Rear Frame ..............................................
Front Upright Frame ...............................
Top Frame ...............................................
Calf Raise / Low Pulley Frame ...............
Top Stack Support Frame ......................
Cable Housing .........................................
2 inch Backing Plate ................................
3 inch Backing Plate ................................
Leg Extension Assembly ........................
Pop Pin - Seat Adjustment .....................
Floating Pulley Bracket ...........................
4 1/2” Pulley ............................................
3 1/2” Pulley ............................................
Roller Bar .................................................
Press Arm ................................................
Press Arm Support Assembly ...............
Press Arm Handle - Right .......................
Press Arm Handle - Left .........................
Foam Roller 8”L ......................................
Roller End Cap ........................................
Plastic Washer.........................................
Snap Cap - Small ....................................
Snap Cap - Large ....................................
Press Arm Pivot Shaft ............................
Press Arm Support Shaft .......................
Seat Adjuster...........................................
Seat Cross Tube ......................................
Back Pad Tube .........................................
Back Pad Adjuster ...................................
Back Pad Adjustment .............................
Seat Pad...................................................
Back Pad ..................................................
Guide Rod ................................................
Weight Stack Bottom Plate ....................
Selector Stem..........................................
Top Weight ..............................................
Weight Plate ............................................
Guide Rod Holder ...................................
Weight Stack Cushion ............................
Double Floating Pulley Bracket ...........
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
29a
30
31
32
33
34
35
36
37
38
39
40
1
1
1
1
1
1
1
2
1
1
1
1
16
3
1
1
1
1
1
2
2
2
2
2
1
1
1
1
1
1
1
1
1
2
1
1
1
19
1
2
2
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
80
67
68
69
70
71
72
73
74
75
76
77
78
79
1
1
1
1
1
1
2
1
4
12
6
1
2
11
3
2
4
4
65
3
37
1
12
2
6
2
4
1
1
1
1
1
1
4
1
1
1
1
1
1
