Item
Service
Object
Actions
Every
month
Every 3
months
Every 500 km/
6 months
Every 1000 km/
1 year
Every 10000 km/
3 years
Functions
Brake
Adjustment
Before adjusting, make sure
the scooter is turned o and
not being charged.
Tool: 4 mm hex key (the tool
needs to be prepared by the
user).
During adjusting, pull the end
of the brake cable to make the
cable tight.
Notes:
· If the brake is too tight, use
the tool to loosen the screw
by turning it counterclockwise,
pull the disc brake rocker arm
outwards, and then tighten the
screw. If the brake is too loose,
use the tool to loosen the screw
by turning it counterclockwise,
push the disc brake rocker arm
forwards, and then tighten the
screw.
· The scooter is tested under
the conditions of a load of
75 kg, and running at
19,9 mph (32 km/h).
√ √ √
Charging
Charge the scooter at a suitable
temperature. The indicator on
the battery charger is red when
the scooter is charging, and
turns green when the scooter
is fully charged. The control
panel will show the charging
status simultaneously during
charging.
√ √ √
Steering
Turn the handlebar 60° to the
left and right to make sure the
turning angle is correct and the
steering is free from resistance
and stagnation.
√ √
Important
Components
Battery
Assembly
Fully charge the scooter before
leaving it unused for a long
time, and turn it on to charge
every 60 days.
√
Product
Name NAVEE Electric Scooter
Model NKT2208-D32
Dimensions
Vehicle: L × W × H
[1]
44.9 × 19.0 × 46.8 in (1140 × 483 × 1189 mm)
After Folding: L × W × H 44.9 × 19.0 × 19.3 in (1140 × 483 × 490 mm)
Net Weight Vehicle Net Weight 35.7 lbs (16.2 kg)
Rider
Load Range 55.1 - 264.6 lbs (25–120 kg)
Age (years) 16–50 years
Body Length 3’11”–6’6”(120–200 cm)
Assembled
Electric Scooter
Max. Speed 19.9 mph (32 km/h)
General Range
[2]
Approx. 24.9 miles (40 km)
Max. Climbing Angle Approx. 15%
Suitable Surfaces
Cement or asphalt road, with benches of less than 1 cm or crevices
narrower than 3 cm
Operating Temperature 14–104 ° F (-10 to 40 °C
）
Storage Temperature -4–113 ° F (-20 to 45 °C)
IP Rating IP55
Charging Time Approx. 4.5 h
Battery Pack
Model T2208-BA3B
Nominal Voltage 36 V
Max. Charge Voltage 42 V
Rated Energy 275.4 Wh
Intelligent Battery
Management System
Over-heating, short circuit, over-current, over-discharge, and
over-charge protection
Normal Charging Temperature
Range
32–104 ° F (0 to 40 °C
）
Rated Capacity 7.65 Ah
Wheel Motor Rated Power 350 W (0.35 kW)
Battery Charger
Model
[3]
BCTA+71420-1701
Output Power 69.7 W (0.0697 kW)
Input Voltage 100–240 V~
Max. Output Voltage 42 V
Rated Output 41 V 1.7 A
Tire Front & Back Tires 10-inch pneumatic tires
Bluetooth
Frequency Band
2402-2480 MHz
Max. RF Power
3.95 dBm
[1] Vehicle height: From the ground to the top of the scooter.
[2] General range: Measured when there is no wind and at 77 ° F (25 ° C), the scooter is fully charged to ride at a constant speed of 9.3 mph
(15 km/h) on a flat surface with a load of 165.3 lbs (75 kg)
[3] To recharge the battery, only use the battery charger provided in the package. Please see battery charger parameters in Specifications.
11. Specifications
