Navistar N10 User Manual

161DIAGNOSTICTROUBLESHOOTINGPROCEDURES
SPNFMISub-sectionConditionDescription
265910AMS(page381)EGRSlowResponseFault
265914AMS(page381)EGRSystemowrateerrorduringAirManagementTest
265920AMS(page381)EGRHighFlowRatedetected
265921AMS(page381)EGRLowFlowRatedetected
27912EGR(page1074)EGRfeedbackcommunicationfault
27913EGR(page1074)EGRVsupplyvoltageistooHIGH
27914EGR(page1074)EGRVsupplyvoltageistooLOW
27917EGR(page1074)EGRValveunabletoachievecommandedposition
27918EGR(page1074)EGRvalvenotreceivingECMPWMsignal
279112EGR(page1074)EGRValveInternalselftestfault
279114EGR(page1074)EGRvalveInitializationFault
27976INJ(page1365)InjectorControlGroup1-shortcircuit(INJ1,2,3)
27986INJ(page1365)InjectorControlGroup2-shortcircuit(INJ4,5,6)
30312DEFTLT(page746)DEFTTsignalerratic,intermittentorincorrect
30313DEFTLT(page746)DEFTTsignalOutofRangeHIGH
30314DEFTLT(page746)DEFTTsignalOutofRangeLOW
30552INJ(page1365)ICP/IPRAdaptationIn-RangeFault
306131CSERExhaustwarmuptimefault
32164NO
X
(page1827)NOxINsignalOutofRangeLOW
321610NO
X
(page1827)NOxINsignalabnormalrateofchange
321613NO
X
(page1827)NOxINOutofCalibration
321619NO
X
(page1827)NOxINnotdetectedonJ1939
321620NO
X
(page1827)NOxINsignaldriftedHIGH
321621NO
X
(page1827)NOxINsignaldriftedLOW
32182NO
X
(page1827)NOxINpowersupplysignalerratic,intermittentorincorrect
32262NO
X
(page1827)NOxOUTsignalerratic,intermittentorincorrect
32264NO
X
(page1827)NOxOUTsignalOutofRangeLOW
322610NO
X
(page1827)NOxOUTsignalabnormalrateofchange
322613NO
X
(page1827)NOxOUTOutofCalibration
322619NO
X
(page1827)NOxOUTnotdetectedonJ1939
322620NO
X
(page1827)NOxOUTsignaldriftedHIGH
322621NO
X
(page1827)NOxOUTsignaldriftedLOW
32282NO
X
(page1827)NOxOUTpowersupplysignalerratic,intermittentorincorrect
32420DPFIT(page876)DPFITaboveCriticalT emperature
32422DPFIT(page876)DPFITsignalerratic,intermittent,orincorrect
