INSTALLATION/ SERVICE MANUAL
1
FLASH
CODES
FLASH CODE
MESSAGE
DESCRIPTION SOLUTION HOW TO CHECK
1-1 Throttle Fault The foot switch is
not engaged and the
throttle signal voltage
is above minimum
throttle parameter.
This indicates the
foot switch is not
coming on or the
throttle has broken
where its off voltage
is to high
• Check wiring
• Replace throttle
• The diagnostic page of the App will
give you readings for the throttle
voltage and foot switch.
• Put the vehicle in neutral and
slowly depress the throttle.
• The foot switch should change from
Off to On before the throttle voltage
reaches around 1V.
• Standard throttles usually read
0.5V when off. The minimum
voltage to start the vehicle is
usually 1V. The maximum when
depressed should read around 4V.
1-2 Brake Fault The analog brake
signal is higher than
the high voltage
threshold which is
4.64V.
These types of brake
pedals are only
installed on certain
types of vehicles such
as RXV’s.
• Check wiring
• Replace brake switch
• The diagnostic page of the App
will give you readings for the brake
voltage
• Put the vehicle in neutral and
slowly depress the brake.
• Standard analog brakes usually
read 0.5V when off. The minimum
voltage to stop the vehicle is
usually 1V. The maximum when
depressed should read around 3V
to 4V
1-3 Charger
Interlock
Charger is connected
and the vehicle is not
in neutral.
Vehicle charging port
may be wet Club Car
On Board Computer
(OBC) is in sleep
mode.
• Disconnect the
Charger before trying
to move.
• Dry and clean the
charger port
• Depress the throttle
twice to wake up OBC.
• Replace charger port
on vehicle
• The diagnostic page of the App will
give you readings for the charger
input connected signal.
• The charger input will read
off when there is no charger
connected.
1-4 Temperature
(Controller)
Performance is
limited because the
controller is hot.
• Let vehicle cool
off, system is over
worked.
Check the temperature of the
controller with a non-contact
temperature sensor
1 - 5 Temperature
(Motor)
Performance is
limited because the
motor is hot.
• Let vehicle cool
off, system is over
worked.
• Check the temperature of the motor
with a non-contact temperature
sensor.
TROUBLESHOOTING
* Check the ‘Caution’ icon on app rst for fault descriptions or refer to the chart below
To Next Page
