NAX 100C - Technical Data

EN 35
TECHNICAL DATA
CIRCULAR COMBUSTION SAW
Type, model
NAX 100C
Engine
TT-1E34F series BS
Fuel mix
40: 1 (4 l of gasoline for every 100 ml of two-stroke oil)
Fuel tank capacity
230 cm
3
Mix oil (recommended)
Briggs & Stratton for two-stroke engines
Oil for lubricating the chain
NAX
Oil tank capacity for chain lubrication
160 cm
3
Engine capacity
25.4 cc
Machine rated power
0.75 kW – 8500 rpm
Maximum torque
1.0 Nm - 6500 rpm
Spark plug
TORCH L8RTF
Maximum engine speed with cutting attachment
10500 rpm
Maximum engine idle speed
3300 ± 500 rpm
Gearwheel
6T X 3/8’’
Chain scale
3/8’’
Chain thickness
1.3 mm
Number of chain links
40 pieces
Guide length
10’’ (25 cm)
Maximum chain feed speed
~ 19 m/s
Sound pressure level
LpA= 93.4 dB(A) K =3 dB
The value of vibrations transmitted by the machine and acting
on the operator's upper limbs
front handle a front_hv, eq 7.128 m/s
2
rear handle a rear_hv, eq 6.895 m/s
2
K= 1.5 m/s
2
Guaranteed sound power level LWA
117 dB(A)
Equipment mass
3.5 kg
Year of manufacture
2022
THE DEVICE INCLUDES:
 petrol chain saw (power supply unit, guide bar guard, guide bar, chain, butt),
 screws, nuts, necessary wrenches,
 operation manual, EC declaration of conformity, warranty conditions, warranty card.
