Nayax Onyx User Manual

Onyx User Manual Onyx_User_Manual_Ver.1.5 Page 15
No.
Title
Description
1.
Onyx
Connector
Onyx cable connector (same connector for both
MDB and Pulse cables).
Note: To disconnect the connector, press the
latch (indicated with an arrow) before pulling out
the cable.
2.
External
Antenna
Adapter
The External Antenna adapter connects to the
board and to the external antenna that is
provided by Nayax.
3.
Sim
Socket
The SIM socket is opened by pulling up and
closed by puling down the socket.
3. Test payment for contactless cards. In case of an error, send it the Nayax Laboratory for
further tests.

Nayax Onyx Specifications

General

Category	Card Reader
Contactless Payment	Yes
Operating Temperature	-10°C to 50°C
Payment Methods	Credit/Debit cards, Mobile wallets
Connectivity	Bluetooth, Wi-Fi, 4G
Security	PCI PTS 5.x
Card Reader Type	Chip, Contactless
Certifications	EMV
Battery Life	Up to 8 hours
Storage Temperature	-20°C to 70°C
Compliance	PCI DSS
