Extra Accessory
Slotted Window Panel
12
Front l0 Cover - Round
Tall Feet
14
16
Front l0 Cover - Angle
VGPU Kit
(lnclude PCle Riser Cable + Bracket)
15
17
Power Supply Bracket - ATX
13
Glass Window Panel
11
Flatpack Assembly Manual
Screw-5
M3 Flat Sunk Screw
M3 FemaleStandoff Screw
Standoff-6
Parts
Side Panels x2
5
Power Supply Inlet Cable
9
Front Panel
1
Bottom Panel
7
Motherboard Tray
3
Top Panel
6
Rear Panel
2
Power Supply Bracket - SFX
8
Fan + Radiator Bracket
4
DO NOT overtighten screws. Once resistance is encountered,
do not tighten more than one-quarter turn.
Each fastener is different in length or head-shape, and putting them next to
each other is a good way to identify them.
This screw only works for countersunk holes,
and has a slightly stronger lock.
This screw works for all of the steps in this
manual. One-screw-ts-all is easier to build.
This screw is custom designed to work with
both regular and countersunk holes.
1
2
3
4
5
6
7
8
9
M3 Countersunk Screw
CScrew-6
CScrew-4
M3 Countersunk Screw
Thumbscrew-10
M3 Thumb Screw
PSbracket-10
M3 PowerSupplyBracket Screw
Flatpack Assembly Manual
OR
To Next Page
