NDS POWERSERVICE PLUS 25 User Manual

13.
27
N°
protection
fuse type
1
main power supply (iec socket)
only gold series
40a blade fuse
univaL type
2
STARTER BATTERY power line (pin n°3)
70a blade fuse
maxval type
3
aux line (pin n°5)
non for plus12-24 and Gold 12-24 models
40a blade fuse
univaL type
4
out line (pin n°6)
25a blade fuse
univaL type
5
out line (pin n°6)
25a blade fuse
univaL type
6
solar panel line (pin n°7)
non for 24V output models
25a blade fuse
univaL type
7
main power supply (iec socket)
only gold series
10a glass type 5x20
fuse
NOTe
•
all the connection pins you can find in the upper table are
explained at page 14 chapter 7: connections.
•
fuses 4 and 5 are connected in parallel and they are
connected both to pin n°6.
• By replacing the fuses, the powerservice will perform an
automatic restart.
•
In case of further additional faults, contact the NDS
energy service center promptly.

NDS POWERSERVICE PLUS 25 Specifications

General

Brand	NDS
Model	POWERSERVICE PLUS 25
Category	Battery Charger
Language	English
