AS241F
Monitor Specifications AccuSync AS241F Notes
LCD Module Diagonal:
Viewable Image Size:
Native Resolution:
60.47 cm/23.8 inches
60.47 cm/23.8 inches
1920 x 1080 60 Hz
Active matrix; thin film transistor (TFT) liquid crystal
display (LCD); 0.275 mm dot pitch; 250 cd/m
2
white
luminance; 1000:1 contrast ratio (typical).
Input Signal
VGA: Mini D-Sub 15-pin: Analog RGB
Sync
0.7 Vp-p/75 ohm
Separate sync.TTL level Positive/Negative
DisplayPort: DisplayPort Connector: Digital RGB Up to 1920 x 1080 60 Hz, DisplayPort V1.1a
(HDCP 1.3)
HDMI: HDMI Connector: Digital RGB, Digital YUV Up to 1920 x 1080 60 Hz, HDMI (HDCP 1.4)
Display Colors 16777216 Depends on display card used.
Synchronization Range Horizontal:
Vertical:
31.5 kHz to 83.0 kHz
50 Hz to 75 Hz
Automatically
Automatically
Viewing Angle Left/Right:
Up/Down:
±89° (CR > 10)
±89° (CR > 10)
Response Time 6 ms (Gray to Gray Typ.)
Active Display Area Horiz.:
Vert.:
527.0 mm/20.7 inches
296.5 mm/11.7 inches
AUDIO
AUDIO Input: STEREO Mini Jack:
DisplayPort Connector:
HDMI Connector:
Analog Audio
Digital Audio
Digital Audio
Stereo L/R 500mV rms 20 Kohm
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
PCM 2ch 32, 44.1, 48 kHz (16/20/24bit)
Headphone Output: STEREO Mini Jack: Headphone Impedance 32 Ohm
Speakers Practical Audio Output: 1.0 W+ 1.0 W
Power Supply AC 100-240 V, 50/60 Hz
Current Rating 0.60 - 0.35 A
Dimensions 538.1 mm (W) x 408.0 (H) x 182.0 mm (D)
21.2 inches (W) x 16.1 inches (H) x 7.2 inches (D)
Stand adjustable range Tilt: UP 20° Down 5°
Weight 3.5 kg (7.7 lbs) (with monitor stand)/3.1 kg (6.8 lbs) (without monitor stand)
Environmental Considerations
Operating Temperature:
Humidity:
Altitude:
Storage Temperature:
Humidity:
Altitude:
5°C to 35°C/41°F to 95°F
20% to 80%
0 to 16,404 Feet/0 to 5,000 m
-10°C to 60°C/14°F to 140°F
10% to 85%
0 to 40,000 Feet/0 to 12,192 m
NOTE: Technical specifications are subject to change without notice.
