3. Connect one end of the power cord to the monitor and the other end to the power outlet. Use the Cable holder to keep the
Video Signal Cable, Audio cable and power cord together (Figure B.1).
4. To attach the Cable Holder:
Attach the Cable Holder on to the Base. Insert the hooks on the Cable Holder into the holes at the back of the Stand and
slide the Cable Holder downward into place (Figure B.1).
NOTE: Please confirm that the tabs are completely secure.
NOTE: Adjust position of cable that place under the Cable holder to avoid damage for cable or monitor.
NOTE: Please refer to Caution section of this manual for proper selection of power cord.
5. Turn on the monitor with the front power button and the computer (Figure C.1).
6. Select input source by Source button or Input Select on OSD menu.
Figure B.1
Cable holder
Figure C.1
Power Button
Input (DVI)
Audio Cable
Input (VGA)
Power Cable
Input (HDMI)
Headphone
7. No-touch Auto Adjust automatically adjusts the monitor to optimal settings upon initial setup for most timings.
For further adjustments, use the following OSD controls:
• Image Setup
Refer to the Controls section of this User’s Manual for a full description of these OSD controls.
NOTE: If you have any problem, please refer to the Troubleshooting section of this User’s Manual.
