5.
At the LD Individual Bind/Unbind
window, select
Pool Binding
under the
Binding Wizard
section at
the bottom.
6.
At the Welcome window for the Pool
Binding Wizard, click
Nex
t
.
NEC D3/D4 Quick Start Guide
36
