- 9-
Table 3.4 NEC Storage M700 Product Specifications
Numbers in the table are calculated based on 1 GB = 1,000,000,000 bytes and 1TB = 1,000,000,000,000 bytes.
Product Name NEC Storage M700 Disk Array Unit
Configuration 2.5”(24HDD model) 3.5”(12HDD model)
Storage
capacity
*1 *2
min max min max
SAS HDD
configuration
300GB disk drive 282GB 243.3TB 282GB 243.3TB
600GB disk drive 571GB 489.4TB 571GB 489.4TB
600GB
drive
571GB 489.4TB 571GB 489.4TB
900GB disk drive 874GB 747.9TB - -
1.2TB disk drive 1.16TB 996.5TB - -
NL-SAS HDD
configuration
2TB disk drive - - 1.9TB 1668.1TB
3TB disk drive - - 2.9TB 2490.9TB
4TB disk drive - - 3.9TB 3334.9TB
SAS SSD
configuration
100GB drive 89GB 897GB 89GB 897GB
200GB drive 187GB 1.4TB 187GB 1.4TB
400GB drive 387GB 3.7TB 387GB 3.7TB
800GB drive 757GB 5.9TB 757GB 5.9TB
Chassis
dimensions
(W×D×H)
Disk array
controller
(U count)
without Front Bezel
480×602.5×175.4mm(4U)
with Front Bezel 480×639×175.4mm(4U)
Disk enclosure
(U count)
without Front Bezel
482×513.2×87.8mm(2U)
with Front Bezel 482×545.2×87.8mm(2U)
Weight
Disk array controller < 48kg
Disk enclosure < 29kg
Accessories (Rails for rack mount,
cables)
< 3kg
Power
Supply
100V to 240V AC, single phase 50/60Hz *3
Power
consumption
8Gb FC 1100W
1G iSCSI 1090W
10G iSCSI 1130W
Disk
enclosure
SAS HDD (3.5”15krpm) - 315W
SAS HDD (2.5”10krpm) 310W -
NL-SAS HDD
(3.5”7.2krpm)
- 265W
Inrush
current
(peak)
Main chassis AC:25Ao-p/AC line
Disk enclosure AC:25Ao-p/AC line
Temperature / Humidity conditions
During operation : +5C to +40C / 10% to 80％
During storage : -10C to +60C / 5% to 80％
Redundancy
Main components such as controller, cache, power supply, and fan are
duplicated
