- 7-
Table 3.2 NEC Storage M300 Product Specifications
Numbers in the table are calculated based on 1 GB = 1,000,000,000 bytes and 1TB = 1,000,000,000,000 bytes.
Product Name NEC Storage M300 Disk Array Unit
Configuration
2.5”(24HDD model) 3.5”(12HDD model)
min max min max
Storage
capacity
*1 *2
SAS HDD
configuration
300GB disk drive 282GB 36.4TB 282GB 24.3TB
450GB disk drive 435GB 56.0TB 435GB 37.3TB
600GB disk drive 571GB 73.4TB 571GB 48.9TB
600GB encrypted disk drive 571GB 73.4TB 571GB 48.9TB
900GB disk drive 874GB 112.1TB - -
1.2TB disk drive 1.16TB 149.4TB - -
NL-SAS HDD
configuration
1TB disk drive 979GB 125.7TB 979GB 83.7TB
2TB disk drive - - 1.9TB 166.8TB
3TB disk drive - - 2.9TB 249.0TB
4TB disk drive - - 3.9TB 333.4TB
SAS SSD
configuration
100GB drive 89GB 897GB 89GB 897GB
200GB drive 187GB 1.4TB 187GB 1.4TB
400GB drive 387GB 3.7TB 387GB 3.7TB
800GB drive 757GB 5.9TB 757GB 5.9TB
Chassis
dimensions
(W×D×H)
Disk array
controller
(U count)
without Front Bezel 482×513.2×87.8mm(2U)
with Front Bezel 482×545.2×87.8mm(2U)
Disk enclosure
(U count)
without Front Bezel 482×513.2×87.8mm(2U)
with Front Bezel 482×545.2×87.8mm(2U)
Weight
Disk array controller < 31kg
Disk enclosure < 29kg
Accessories (Rails for rack mount, cables) < 3kg
Power
Supply
100V to 240V AC, single phase 50/60Hz *3
Power
consumption
SAS HDD configuration
(3.5”15Krpm)
- - 510W 2715W
SAS HDD configuration
(2.5”15Krpm)
505W 2055W - -
SAS HDD configuration
(2.5”10Krpm)
505W 2055W - -
NL-SAS HDD configuration
(2.5”/3.5”7.2Krpm)
470W 1845W 455W 2310W
Inrush
current
(peak)
Main chassis 25Ao-p/AC line
Disk enclosure 25Ao-p/AC line
Temperature / Humidity conditions
During operation : +5C to +40C / 10% to 80％
During storage : -10C to +60C / 5% to 80％
Redundancy
Main components such as controller, cache, power s
upply,
and fan are duplicated
