■Available SFP Module combination for Host Port Card(10Gb iSCSI Optical 4Port) [NF5322-SF22E]
The following table shows available SFP combination in case of M110 disk array(dual controller)
with two Host Port Card(10Gb iSCSI Optical 4Port).
Port combination
per unit
10Gb iSCSI Optical SFP
[NF5322-SFP10E]
10G iSCSI Optical
2Port
1
10G iSCSI Optical
4Port
2
10G iSCSI Optical
6Port
3
10G iSCSI Optical
8Port
4
The following table shows available SFP combination in case of M110 disk array(single controller)
with two Host Port Card(10Gb iSCSI Optical 4Port).
Port combination
per unit
10Gb iSCSI Optical SFP
[NF5322-SFP10E]
10G iSCSI Optical
2Port
1
10G iSCSI Optical
4Port
2
2. M110 Component Selection (10)
Max 8 SFPs (corresponded to 4-Model
Number) per unit are available.
Max 4 SFPs (corresponded to 2-Model
Number) per unit are available.
